MULTI FUNCTIONAL USB SERVER LN-309 Full manual

Sitecom Multi Functional USB server LN-309 4.2.4 Setting the IP Address Using the Control Center • Start the Control Center. The Main window wil

Please check www.sitecom.com for up to date drivers & utilities, manuals and support • Click the button corresponding to your choice of IP set

Sitecom Multi Functional USB server LN-309 • A web page “System Status” is shown. Please click Basic Settings. • And then click the TCP/I

Please check www.sitecom.com for up to date drivers & utilities, manuals and support • Select the button which corresponds with your choice of

Sitecom Multi Functional USB server LN-309 5. Print Server in Windows 5.1 Connecting the Server To configure your Server correctly, you should k

Please check www.sitecom.com for up to date drivers & utilities, manuals and support Before using network printer, you have to turn on “Use Printe

Sitecom Multi Functional USB server LN-309 6.3 Supported Codepages The Server supports Windows codepages. If users want to communicate with the S

Please check www.sitecom.com for up to date drivers & utilities, manuals and support • Open the Control Center • Select the MFP Server from the

Sitecom Multi Functional USB server LN-309 6.4.3 Set up File Server Configuration 6.4.3.1 Set SMB/CIFS Print/File Server • Enable SMB/CIFS P

Please check www.sitecom.com for up to date drivers & utilities, manuals and support • Allow Anonymous Login: select the item, if you want to al

Sitecom Multi Functional USB server LN-309 1. Table of Contents 1. TABLE OF CONTENTS...

Sitecom Multi Functional USB server LN-309 6.6 Using Shared Storage by FTP Methods for Windows • Open Microsoft Internet Explorer. • In the

Please check www.sitecom.com for up to date drivers & utilities, manuals and support 7. NetUSB Mode 7.1 Introduction The Sitecom LN-309 has a to

Sitecom Multi Functional USB server LN-309 You must change the IP address of the MFP server (or use DHCP) so that the MFP server and your PC are

Please check www.sitecom.com for up to date drivers & utilities, manuals and support • Please follow the user manual of the USB device to instal

Sitecom Multi Functional USB server LN-309 • Then, the printer will be marked as an “Auto-Connected Printer” in red. • If you choose “Auto

Please check www.sitecom.com for up to date drivers & utilities, manuals and support • Then try to issue a print job to the desired printer. You

Sitecom Multi Functional USB server LN-309 • Then you can see that the Control Center will automatically do a “connect” operation. The followin

Please check www.sitecom.com for up to date drivers & utilities, manuals and support Before you use NetUSB technology to access USB storage, pleas

Sitecom Multi Functional USB server LN-309 8. Using the Control Center 8.1 Using Tools of Control Center You can use the following tools to hel

Please check www.sitecom.com for up to date drivers & utilities, manuals and support 8.2.3 Supported Protocols • LPR (Line Printer Remote) Prin

Please check www.sitecom.com for up to date drivers & utilities, manuals and support 8.1 USING TOOLS OF CONTROL CENTER ...

Sitecom Multi Functional USB server LN-309 8.3 User Accounts • New Administrator: enter your desired administrator name.(default : admin) • N

Please check www.sitecom.com for up to date drivers & utilities, manuals and support 8.4 SNMP • Authentic Community: set Community name of SNM

Sitecom Multi Functional USB server LN-309 8.5 Email If you want to receive alert mails from the Server, you have to enable SMTP Protocol, and

Please check www.sitecom.com for up to date drivers & utilities, manuals and support 8.6 Maintenance To restart the Server, restore the Server

Sitecom Multi Functional USB server LN-309 Note： The Control Center doesn’t really quit if you click the “X” box (close box) at the top right c

Please check www.sitecom.com for up to date drivers & utilities, manuals and support 9. The Server’s Web Pages 9.1 Introduction By using the we

Sitecom Multi Functional USB server LN-309 9.3.2 TCP/IP Configuration To set the MFP server’s TCP/IP configuration and connect TCP/IP network, pl

Please check www.sitecom.com for up to date drivers & utilities, manuals and support • Maximum Session Number: enter or clear Maximum Session Num

Sitecom Multi Functional USB server LN-309 • New Password: enter your desired password • Retype Password: confirm your previous password typing.

Please check www.sitecom.com for up to date drivers & utilities, manuals and support • SNMP V3: select or clear SnmpV3 support. • User Security

Sitecom Multi Functional USB server LN-309 2. Introduction 2.1 Thank you Thank you for buying the Sitecom Multi Functional USB Server LN-309. Wi

Sitecom Multi Functional USB server LN-309 9.5.2 Restart Click the Apply button, the Server will be restarted. 9.5.3 Restore Click the Apply

Please check www.sitecom.com for up to date drivers & utilities, manuals and support 10. Restore Factory Defaults 10.1 Using the Control Center

Sitecom Multi Functional USB server LN-309 11. Upgrade Firmware Note： Before starting to upgrade the firmware, please do power off and on the MFP

Please check www.sitecom.com for up to date drivers & utilities, manuals and support 11.2 Using the Server’s Web Pages • Power on the Server. Su

Sitecom Multi Functional USB server LN-309 Note： Please note that after that, the Server will operate using the factory default values after resta

Please check www.sitecom.com for up to date drivers & utilities, manuals and support 3. Product Overview 3.1 Package Contents • The MFP Server (

Sitecom Multi Functional USB server LN-309 3.3 Features and Benefits This Server provides the following features and benefits: • Reliability: T

Please check www.sitecom.com for up to date drivers & utilities, manuals and support 4. Basic Installation & Configuration 4.1 Connecting the

Sitecom Multi Functional USB server LN-309 • Select “Use the following IP address”. And then put the factory default IP <192.168.0.200> a

Please check www.sitecom.com for up to date drivers & utilities, manuals and support 4.2.3 Installing Control Center software • Install the LN-3
